T-WORKS Hydraulic Press In Pile Driver With Piling Force 120T for Concrete Spun and Square Pile
1. Description:
ZYC series hydraulic static pile driver is a new environmentally friendly pile foundation construction equipment with a number of national patents. It has the features of no pollution, no noise, no vibration, and fast pile driving, high quality pile. It is represent the future development tendency of pilling machinery.
2. Applications:
- Clay, soft soil, sand layer, etc.
- Noise regulated urban area.
- Vibration regulated areas where traditional methods may threaten the stability of existing structures.
3. Specifications:
| Item | Model/size | Item | Model/size |
| Main pushing cylinder | 180/125-1600 | Pushing stroke | 1.6m |
| Assistant pushing cylinder | 180/125-1600 | Pushing stroke | 1.6m |
| Outrigger cylinder | 180/125-1450 | Stroke for outrigger cylinder | 1.45m |
| Long boat cylinder | 110/70-1500 | Stroke for long boat | 1.5m |
| Short boat cylinder | 110/70-400 | Stroke for short boat | 0.4m |
| Clamping cylinder | 210/160-30 | Clamping box | 4 cylinders type |
| Crane capacity | 8 ton X 12 meters | Pumps for pile pushing | 2 * A7V58 |
| Side jacking mechanism | Hanging type | Engine motor for pile pushing | 2* 18.5KW |
| Main working pressure | 24Mpa | Pumps for crane | 1 * 63YCY |
| Piling speed | 6.3m/min | Engine motor for crane | 1 * 22KW |
| Max spun pile | 350mm | Max square pile | 350 mm |
| Min working size | 9.45m x 5.25m | Min weight for main body | 21 ton |
| Weight of main machine | 50 ton | Counterweight needed | 70 ton |
| Total capacity | 120 ton |
4. Feature Advantage:
1). Civilized construction; Clean; No noise; No vibrations; No construction wastes.
2). Reliable Construction Quality; Piling process is similar to static load testing, where pile bearing force can be displayed. 100% pile success rate is guaranteed.
3). Fast piling and High efficiency; One Hydraulic Static Pile Driver (shortened as HSPD )can drive piles in total of 600~800m per 8 hours, much faster than other modes. Especially suitable for large-scale or time-constraint projects.
4). Walking and steering freely. Easy to align piles.
5). Compact conformation. Easy to disassemble & assemble.
